Geared head milling machine designed for milling, drilling, tapping, boring and reaming applications, with a large 800mm x 240mm work table and 240V single-phase operation.
- DM45 Geared Head Milling Machine 240V - Metex
- Maximum drilling capacity: 45mm
- Maximum face milling capacity: 80mm
- Maximum end milling capacity: 32mm
- 800mm x 240mm work table with 85kg capacity
- X-axis longitudinal table travel: 500mm
- Y-axis cross table travel: 225mm
- Maximum spindle nose to table distance: 470mm
- Maximum throat depth: 258mm
- MT4 spindle taper as standard, with R8 configuration available
- 120mm spindle travel with micro-feed control
- Six spindle speeds: 75, 170, 280, 540, 960 and 1600 RPM
- Milling head swivels ±90°
- 1500W, 240V single-phase, 50Hz motor with 10A supply
- Tapping mode for compatible threading operations
- Tapered roller bearing spindle with spindle lock
- Adjustable table gibs and table stops
- Dovetail column with expansion bellows protection
- Work light and safety chuck cover
- Three 14mm table T-slots suitable for an M12 clamping set
- Required work area: 2000mm x 2600mm x 2200mm
- Shipping Australia Wide
- Commercial-grade equipment for professional use
This product is intended for commercial or professional use. Installation or setup may require a qualified professional. Please review specifications and ensure suitability before purchase.
| Shipping | Freight calculated at checkout. Tracked shipping Australia-wide. |
| Delivery | Estimated between and . Dispatch times vary by product. Delivery is ground-level or kerbside for large items. Ensure suitable access for pallet freight. |
Description
Geared head milling machine designed for milling, drilling, tapping, boring and reaming applications, with a large 800mm x 240mm work table and 240V single-phase operation.
- DM45 Geared Head Milling Machine 240V - Metex
- Maximum drilling capacity: 45mm
- Maximum face milling capacity: 80mm
- Maximum end milling capacity: 32mm
- 800mm x 240mm work table with 85kg capacity
- X-axis longitudinal table travel: 500mm
- Y-axis cross table travel: 225mm
- Maximum spindle nose to table distance: 470mm
- Maximum throat depth: 258mm
- MT4 spindle taper as standard, with R8 configuration available
- 120mm spindle travel with micro-feed control
- Six spindle speeds: 75, 170, 280, 540, 960 and 1600 RPM
- Milling head swivels ±90°
- 1500W, 240V single-phase, 50Hz motor with 10A supply
- Tapping mode for compatible threading operations
- Tapered roller bearing spindle with spindle lock
- Adjustable table gibs and table stops
- Dovetail column with expansion bellows protection
- Work light and safety chuck cover
- Three 14mm table T-slots suitable for an M12 clamping set
- Required work area: 2000mm x 2600mm x 2200mm
- Shipping Australia Wide
- Commercial-grade equipment for professional use
This product is intended for commercial or professional use. Installation or setup may require a qualified professional. Please review specifications and ensure suitability before purchase.
